Summary:
◆ Applicable scope: electric wire and cable, all kinds of household appliances, industrial electric appliances, chemical industry, and medical instruments.
Features:
◆ Use the advanced digital circuit technology, can control the occurrence and stop of the output voltage automatically.
◆ When the specimen’s leakage current exceeds the preset, it will cut off the output voltage automatically, and give out sound-light alarm, and indicates the leakage current value.
◆ Testing voltage, leakage current, and test time are all digital display, which can directly, precisely, fast and reliably measure the specimen’s breakdown voltage and current leakage.
Standards:
GB4706.1
IEC 60335
CCC, UL, VDE, CSA, and JIS
Technical parameters:
| Type | LK2670AX | LK2671B | LK2672D |
| Testing voltage | AC 0~5kv | AC/DC 0~10kv | AC 0~5kv |
| Leakage current | AC 0~20mA | AC 0~20mA DC 0~10mA | AC 0~100mA |
| Testing time | 1~99s | ||
| Transformer capacity | 500VA | 750VA | 750VA |
| Measurement accuracy | ±3%±3 | ||
| Others | Super leakage alarm | ||
